Ref. 8226- USED UTECO DIAMOND HP 108, YEAR 2011
- Manufacturer: UTECO
- Model: DIAMOND HP 108
- Year: 2011
- Number of colors 10
- Print possibilities 10+0, 10+10
- Overhaul/renovation: a retrofit of the electronic parts and a 100×100 print inspection carried out in 2019.
- Gearless: Yes
- Fast sleeve change: Yes
- 4 motor per deck CNC position system: Yes
- Computer supervision: Yes
- Web width (mm): 1550
- Print width (mm): 1500
- Min print repeat (mm): 420
- Max print repeat (mm): 870
- Unwinder type Turret: automatic
- Max reel diameter unwinder (mm): 1000
- Rewinder type: Turret automatic
- Max reel diameter rewinder (mm): 1000
- Drying: 2 zones 4 fans with 6 mt final tunnel and thermo oil heat exchangers
- Videocamera: GRAFYKONTROL
- Web guides: yes, BST
- Washing system: Yes, automatic
- Inking system: Closed chamber doctor blades
- Anilox 16
- Print Sleeves 50
- Additional Information:
- Printing speed max 600 mpm
- Carbon fiber mandrels
- Automatic printing set up and automatic register control with «click and drag» system by GRAFYKONTROL
- Drum cleaning device
- 100×100 defect control by Grafikontrol
- Turning bar 10+10 half width
- …
