Ref. 4045- Used REIFENHAUSER, year 2003
- Manufacturer: REIFENHAUSER
- Year: 2003
- Number of layers: 3
- Film structure: ABC
- Material: LDPE, LLDPE, MDPE Others in blends
- Film Width: 2300
- Output (Kg/h): 400
- Extruder 1 Layer ref: : A
- Screw diam 1: 60
- Description 1: AC motor 60 kW , Gravimetric dosing system Doteco 5 comp
- Extruder 2 Layer ref: : B
- Screw diam 2: 80
- Description 2: AC motor 117 kW , Gravimetric dosing system Doteco 5 comp
- Extruder 3 Layer ref: : C
- Screw diam 3: 60
- Description 3: AC motor 60 kW , Gravimetric dosing system Doteco 5 comp
- Die diam (mm): 400 mm + 280mm
- Thickness control system: Automatic thickness profile control
- Bubble cage: Motorized
- Panel for gussets: Yes
- Take off unit: oscillating take off unit Reinhold wide 2300 mm with gusseting panels
- Corona treatment: MERO
- Web guide: E+L
- Rewinder Type: Double back to back
- Rewinder max reel diameter: 1000
- Rewinder description: Model UFA 01 A1
- Additional Information: Edge trim shredding Exact and recovery regranulator Macchi RecotrimChiller Eurochiller
- …
