Ref. 4084- TECOM COEX 40-50-40B/1300, year 2024 (NEW)
- Manufacturer: TECOM
- Model: COEX 40-50-40B/1300
- Year: 2024 (NEW, DELIVERED SUMMER 2024)
- Film structure: ABC
- Extruder A TYPE EXK 50 B: screw diameter 50 mm, ratio L/D=30
- Extruder BC TYPE EXK 40 B: screw diameter 40 mm, ratio L/D=30
- Relationship between layers: Central layer B up to 70%, Inner and External A – C from 10% to 30%
- Materials: HDPE, MDPE, LDPE, LLDPE, mLLDPE, BIO and recycled materials, relatively to the die gap and screw profile provided. Normal bubble shape and/or long neck bubble shape.
- Width: max 1250 mm – min 650 mm
- Thickness: LDPE from 20 to 150 um, HDPE from 10 to 80 um, BIO from 10 to 10 um, with materials of suitable viscosity for the thickness demands, corrected blow up ratio and speed of the line.
- Speed: up to 90 m/min
- Output: Up to 150 Kg/h with a diameter die of 180 mm
- Tolerance on the medium thickness: +/- 7/8% with thickness of 60 um, according to the workable materials characteristics, blow up ratio and speed line.
- Qt.1 EXTRUDER TYPE EXK 50 B
- Qt.2 EXTRUDER TYPE EXK 40 B
- Q1t. IN-LINE CARTRIDGE SCREEN-CHANGER CSL2 COEX
- Qt.2 CARTRIDGE SCREEN-CHANGER CS2 COEX
- Qt. 1 THREE-LAYER CO-EXTRUSION HEAD TSFK1 10/22 (Die’s diameter 180 mm with die gap 1.5 mm)
- Qt. 1 COOLING RING KRA35
- Qt.1 BUBBLE GUIDE CALIBRATOR FRAME LC120-6-L5-CFK-RVQ-H1500+I+PD
- Qt.1 OSCILLATING TAKE-OFF UNIT RTO1
- Qt.1 DIGITAL EDGE GUIDE TYPE LE DRB 3331
- Qt.1 ONE-FLOOR TOWER FOR OSCILLATING TAKE-OFF UNIT RTO1
- Qt.1 DOUBLE BACK-TO-BACK STATION SEMI-AUTOMATIC WINDER R6/2 TUC
- Qt. 1 CONTROL BOARD FOR TAKE-OFF UNIT AND DOUBLE BACK-TO-BACK STATION WINDER R6/2 TUC, rolls width 1300 mm, useful width 1250 mm, speed 90 mt/min, diameter 1000 mm, Knives for lateral and central cut of film/tubular.
- Qt.1 ELECTRIC AND THERMOREGULATION CONTROL BOARD FOR THREE LAYER COEX PLANTS 40-50-40B
- Qt.1 AIR COOLING BATTERY SERIES BRA +25
- Qt.1 CUT-AND-WELD TYPE TS1-A
- Qt.1 GRAVIMETRIC DOSAGE SYSTEM BATCH BLENDER WITH WEIGHT/METER CONTROL GRADO ADROIT 204-204-204, up to 200 kg/h
- …
