Ref. 15119- USED MB HLC/WSL 130/02, YEAR 2001
- Manufacturer: MB
- Model: MB HLC/WSL 130/02
- Year: 2001
- Application: Lamination + coating
- Type of lamination/coating: MULTIPLE COATINGS
- Working width (mm): 1215
- Materials: BOPP, PETP, LDPE, LLDPE, PAPER & LAMINATES, ALU
- Speed: 300 mpm
- First unwinder type: SINGLE POSITION SHAFTLESS
- Max diameter reel unwinder: 1000
- Secondary unwinder type: SINGLE POSITION SHAFTLESS
- Third unwinder type: SINGLE POSITION SHAFTLESS
- Rewinder type: SINGLE POSITION SHAFTLESS
- Max diameter reel rewinder: 1000
- Coating unit: Interchangeable Trolley , Gravure Trolley and Wax/Hot melt trolley
- Second Coating unit: Interchangeable Trolley Solventless trolley , Gravure Trolley
- Drying: 1st coating unit : 4 zones drier with 4 tunnel 2,5 m length each. Tot 10 m , thermo oil heat exchanger 2nd coating unit : vertical hood total length 3 mt
- Register control: Yes
- pumping mixing unit: yes for solventless year 2018
- Corona treatment : Yes Martignoni
- Additional Information:
- Wax Lamination, wax lamination with lacquering, wax coating one side / two side, hot melt full coat / registered, cold seal, wet / dry lamination, Registered lamination, coding .
- Totally 4 trolleys supplied : 1 gravure, 1 gravure for cold seal, solventless, hot melt
- Premelting pumping unit for hot melt
- 2 heating units for solventless trolley
- CO2 fire fighting system
- …
