VENDIDA / SOLD Ref. 25017- Used KROENERT / BMB COATING MAHCINE, year 2012
- Manufacturer: KROENERT / BMB
- Year: 2012
- Application: Coating
- Type of lamination/coating: Primer + barrier lacquers (water based) , Primer + acrylic adhesive/PVdC (double sided). Other applications
- Working width (mm): 1300
- Materials: BOPP 10 – 80 μ;PET 6 – 60 μ;Paper 20 – 150 g/m2;PVC hard (blister) 20 – 300 μ (must be tested);Alu foil soft 7 – 80 μ
- Speed: 300 m/min Max. mechanical speed
- First unwinder type: Automatic Turret
- Max diameter reel unwinder: 1000
- Rewinder type: Automatic rewinder
- Max diameter reel rewinder: 1000
- Drying: Heating system Electric ,1 x 5 meter dryer (for primer),1 x 10 meter dryer (for secondary coating)
- Corona treatment : Yes, AFS on both sides
- Coating rollers: Number and sizes airshafts 6 x 3” ;4 x 6”
- Additional Information: Only 7000 running hours
Min./Max. coating width 700 – 1300 mm
Unwind/rewind shafted
- Web guide: BST EKR 500 Plus
- This machine has two coating stations which both can coat on both sides of the web
Station 1: For primer
- Coat weight dry 0,5 – 1 g/m2
- Solid content: Max 30%
- Station 2: For PVdC/Acryclic adhesive
- Both coating materials have their own Reco 800A trolley which can be changed in the machine.
- …
