Ref. 9062- USED TIQUATTRO ENGINEERING STACK 8 L-1500, YEAR 2004
- Manufacturer: TIQUATTRO ENGINEERING SRL
- Model: STACK 8 L-1500
- Year: 2004
- Stack flexographic printing machine
- Number of colors: 8
- Print possibilities: 8+0, 4+4
- Gearless: No
- Fast sleeve change: No
- Web width (mm): 1580
- Print width (mm): 1500
- Min print repeat (mm): 300
- Max print repeat (mm): 1000
- Unwinder type: Single station with electro-welded steel structure
- Max reel diameter unwinder (mm): 1200
- Rewinder type: Single
- Max reel diameter rewinder (mm): 1200
- Speed: 200 m/min
- Drying: 2 gas burners, each with 60 kW power, Main drying tunnel (accessible)
- Secondary tunnel for reverse-side printing
- Shaft: Pneumatic expanding shaft for cores with internal diameter of 70 mm
- Film tension control via load cell
- Automatic reel loading system
- 8 impression cylinders
- Transverse and longitudinal register with motorized adjustment
- Plate cylinder disengagement with horizontal movement via independent brushless motors for each color
- Laser-engraved anilox rollers (diameter 178 mm)
- Micrometric pressure adjustments via onboard touchscreen control panel
- Stainless steel ink trays with rubber ink pickup roller and electric grinding system
- Calender Unit
- Structure: Steel construction with chrome-plated, ground, motorized pulling calender
- Film Handling: Pneumatic system for nip pressure
- Aluminum guide rollers balanced on high-efficiency bearings
- Sleeves: 400, 450, 500, 550, 600, 650, 700
- …
