Ref. 8237- USED REMAK, YEAR 2006
- Manufacturer: REMAK
- Year: 2006
- Number of colors: 6
- Print possibilities: 6+0
-
Gearless: No
-
Fast sleeve change: No
- Web width: 1400 mm
- Print width: 1350 mm
- Min print repeat (mm): 350
mm
- Max print repeat (mm): 710
mm
- Speed: 200 m/min
- Type of inks: with solvents or water
- Video camera: Yes, Fife camera for printing monitoring
- Web guides: Yes, before drum, FIFE
- Nip roller before winding for tension adjustment – film cooling
- Unwinder type: 2 positions with pneumatic axes for 76 mm, max diameter 1000 mm
-
Rewinder type: double single, single unwinding roller with pneumatic rollers for 76cm mat, with ballerina for automatic tension adjustment, max diameter 800 mm
- Drying: Electric, with resistors and for hot air flow, one motor in the drum, one motor in the drying aisle
-
Main body of the central printing drum with manual anilox pressure and sleeve, 7 electrically driven pumps for ink supply, 7 ink tanks
- 12 series of sleeve cliché cylinders, sleeves available for repetitions: 35, 40, 42, 45, 46.5, 50, 53, 57, 61, 65, 68, 71
- 11 anilox rollers: (lines/volume) 80/18, 80/14, 80/14, 120/9, 120/14, 140/9, 180/7.5, 220/7, 280/5.2, 280/7,280/7
- Central electrical panel removable from the machine, separate chamber
- …
