Ref. 8204- USED UTECO CRYSTAL, YEAR 2018
- Manufacturer: UTECO
- Model: CRYSTAL
- Year: 2018
- Number of colors: 10
- Print possibilities: 10+0
- Gearless: Yes
- Fast sleeve change: Yes
- 4 motor per deck CNC position system: Yes
- Computer supervision: Yes
- Web width (mm): 1050
- Print width (mm): 1000
- Min print repeat (mm): 330
- Max print repeat (mm): 750
- Unwinder type: Turret Automatic with roll loading system
- Max reel diameter unwinder (mm): 1000
- Rewinder type: Turret Automatic with roll unloading system
- Max reel diameter rewinder (mm): 1000
- Drying: 2 zones , 4 fans final tunnel 5 mt , Thermo oil heat exchangers , automatic air recirculation system with LEL control
- Videocamera: Yes Grafikontrol double camera with 100% inspection
- Corona treatment : Yes
- Web guides: yes in and out Fife OPG
- Viscosity control: Yes Automatic Gama G29
- Washing system: Yes automatic
- Inking system: Closed chamber doctor blades
- Anilox: 12 ceramic anilox sleeves
- Print Sleeves: 200 as 10 of each repeat each 10 mm repeat , 330, 340, 350 , 360
- …
