Ref. 7006- USED EXTRUDER UNION TR100-38, YEAR 2015
Manufacturer: UNION
Model: TR100-38 TR50-30 TAVOLA 1200
Year: 2015
Material: PET, PP and HIPS. Can work with virgin or regenerated material. SISTEMA ANTI BOVEDA You have an anti-vault system. But in the door forced feeding.
Extruder: TR100-38 COEX TR50-30
Main screw= 100 mm diameter Co-extruder screw= 50 mm
Sheet/foil structure: ABA and BBB
Die model (L3-AS/CR 1150) = max. plate width 1150 mm
Calander (FC 1200)
Roller length = 1200 mm
Reel diameter : max 1500 mm
Output : 500 kg/h
Speed : 28 m/min
It has a silicone bath, cut side edges and a mill for them.
The Calenders have their own temperature thermoregulator equipment for each of them.
Maximum calender speed 28m / min with the possibility of working at different speeds each roller. The 3 rollers are chrome mirror.
The extruder and the calenders have Master-Slave control to facilitate the work to the operators.
Rewinder type: Double (manual)
The rewinder is UNION of two winding stations. It would be typical for you to activate the accumulator to have time to cut the blade safely and then when you have changed the station they resume the winding. But the action of such and the glued to the axis is manual.
Rewinder Diameter: Max 1500mm
Aditional information:
Minimum sheet thickness = 0,2 mm Maximum sheet thickness = 1,2 mm
