Ref. 6073- USED SML CAST COEX 5, YEAR 2006
- Manufacturer: SML
- Model: CAST COEX 5
- Year: 2006
- Number of layers: 5
- Overhaul/renovation: yes, recent revamp to part of controls
- Film structure: ABCDE
- Material: Stretch film LLDPE
- Film width (mm): 2500
- Speed (m/min): Mech speed 600 mpm- net speed at rewinder 550 mpm
- Output (Kg/h): Nominal capacity 3400 kg /h – Max net capacity at rewinder 2300 kg/h .
- Extruder 1 Layer ref: : A
- Screw diam 1: 90mm
- Description 1: Gravimetric dosing units Doteco 2Comp.
- Extruder 2 Layer ref: : B
- Screw diam 2: 120mm
- Description 2: Gravimetric dosing units Doteco 4 Comp.AC motor, hydraulic screen changer
- Extruder 3 Layer ref: : C
- Screw diam 3: 120mm
- Description 3: Gravimetric dosing units Doteco 4 Comp. AC motor, hydraulic screen changer
- Extruder 4 Layer ref: : D
- Screw diam 4: 120mm
- Description 4: Gravimetric dosing units Doteco 3 Comp.AC motor, hydraulic screen changer
- Extruder 5 Layer ref: : E
- Screw diam 5: 90mm
- Description 5: Gravimetric dosing units Doteco 2 Comp.AC motor, hydraulic screen changer
- Head description: Automatic
- Die head with Internal deckling, Eltex edge pinning,
- Die width (mm): Gross width 3100 – 2100 mm
- Chill roll unit: Double chill roller
- Thickness control system: Yes
- Web guide: Oscillating frame
- Rewinder description: Turret rewinder for machine reels and jumbo
- Additional Information:
- Regrinder for edges and Erema Regranulator
- 3 Kongskilde exhaust for edge trims
- EREMA recycling regranulation unit
- Additional extruder. 8 for recycled material supplied by Erema unit .
- Provision for edge encapsulation .
- Complete end of the line rolls handling and palletizing
- …
