Ref. 5029- USED MACCHI COEX 5, year 2011
- Manufacturer: MACCHI
- Model: Coex5
- Year: 2011
- Number of layers: 5
- Film structure: ABCDE
- Material: Nylon & EVOH-base barrier Film
- Film Width: 2200 mm
- Output (Kg/h): 480 kg/h
- Extruder 1 Layer ref: : A
- Screw diam 1: 65mm
- Description 1: Gravimetric Dosing units – 4-comp. Groove-feed, bi-metal Barrel, barrier Screw Melt Pressure Sensor before screen change
- Extruder 2 Layer ref: : B
- Screw diam 2: 45mm
- Description 2: Gravimetric Dosing units – 1-comp, Groove-feed, bi-metal Barrel, barrier Screw Melt Pressure Sensor before screen change
- Extruder 3 Layer ref: : C
- Screw diam 3: 55mm
- Description 3: Gravimetric Dosing units – 4-comp, Groove-feed, bi-metal Barrel, barrier Screw Melt Pressure Sensor before screen change
- Extruder 4 Layer ref: : D
- Screw diam 4: 45mm
- Description 4: Gravimetric Dosing units – 1-comp, Groove-feed, bi-metal Barrel, barrier Screw Melt Pressure Sensor before screen change
- Extruder 5 Layer ref: : E
- Screw diam 5: 65mm
- Description 5: Gravimetric Dosing units – 4-comp, Groove-feed, bi-metal Barrel, barrier Screw Melt Pressure Sensor before screen change
- Die diam (mm): 450 mm 5-layer Die-head, 10-zones heating, 550 x 2 mm insert for LLDPEIBC with 1 nos. air chiller bubble control, auto inner bubble exchange byhigh speed stepper motored ValveAir ring with 64 heating inserts
- Bubble cage: 1100~2100 mm layflat motorized Calibration Cage, ultrasonic web-break detector
- Take off unit: Horizontal Oscillating Take-up, AC vector drive
- Corona treatment: Yes, 2-side
- Web guide: Yes
- Rewinder Type: Double back to back
- Rewinder max reel diameter: 1200
- Rewinder description: 2-stn contact Winder, 40~250 N web tension, anti- static system. 4 nos. 4ac core air shafts.
- Additional Information:
- Air chiller exchangers for OBC & IBC
- Edge-trim Slitting & blower
- PLC control. 15” Touch-Screen control.
- Max 150 m/min.
- …
