Ref. 21048 – Used ELBA SAV20-12, year 2008
- Manufacturer: ELBA
- Model: SAV20-12
- Year: 2008
- Type of sealing/bags: Multiple type
- Type of bags: 3 side seal, 2 lines of doypack, 1 line of side gusset central seal and quad 4 seals.
- Min/max bag width: 120 – 1200 mm
- Min/max bag length: 80 – 800 mm
- Repeat 1600 mm
- Mechanical Speed: 150 strokes/min
- Max film speed: 50 m/min
- Doypack version with zip:
- Min/max bag width: 100/400 mm
- Min/max bag length 2 lanes: 120/250 mm
- Min/max bottom gusset depth: 20-50 mm
- Zipper distance between centers: 70 mm
- Side gusseted bag width central welding:
- Min/max bag width 100: 500 mm
- Max bag length: 800 mm
- Min/max gusset depth: 20-70 mm
- Bottom welding width: 15 mm
- Central welding width: 10 mm
- Side welding width: 15 mm
- Side gusseted bag with side welding:
- Min bag width: 170 mm
- Max bag width: 320 mm
- Additional Information: Pneumatic movement of sealing bars
- 1 Double unwind stand PBV-12 width 1200 mm. with expansion shafts
- 1 Gusset forming group and longitudinal welding bar type SFL-121
- Continuous perforator group type PPC
- 1 Zipper unwinding and guiding group type PCV-M on 2 lanes
- 1 Longitudinal welders-holder group type I-SI.O-12 equipped with:
- – 2 longitudinal adjustable welding bars type SLO-DRSL with cooling unit
- – 1 quick change
- – 1 double zipper profile
- 1 Additional longitudinal welders-holder group type I-SLO-12 equipped with:
- – 2 longitudinal adjustable welding bars type ST O-DRSL with cooling unit
- – 2 quick changes
- – 2 doypack profiles
- 1 Trim cutting group type RIB
- 2 Transversal welding devices type STR
- 1 Cooling device type DRS
- 1 Automatic welding machine central part type SA V20-12 complete with photocell, cutting blade and exit module type MUV
- 3 Longitudinal cutting groups type TAI.
- 1 Automatic collecting table type TNL-12
