Ref. 20027- USED MAMATA VEGA W 800, YEAR 2022
- Manufacturer: MAMATA
- Model: VEGA W 800
- Year: 2022
- Wicket machine
- Servo driven Unwinder with Servo Tension control and Film Folder for 60″ ( 1525 mm ) wide Rolls…
- Undwinder diameter: 1000 mm
- Motorized Roll Lifting System
- Electric Edge Guide System
- Motorized Sensor Movement
- Motorized Film Folder Movement
- Secondary Edge Guide on 60″ Film Folding Device
- Bottom Gusseter 40mm – 100 mm for (60″) 1525 mm Web
- Linear Perforator (Single Perfo) for 1525 mm (60″) Web
- Perforation Wheel (3.0 mm Cut & 1.0 mm Un Cut)
- String Zipper Sealing System (R.H.), String Zip Unwinder, String Zip Insertion, String Zip Sealing Module, Bypass Roll, Ultrasonic Zip Squeezing Assembly on Attachment Platform
- Main Machine (R.H.) 2500MM with 410 Wicket Arm & 1+4 Pin Stacker
- Edge Guide Sensor for Pin Stacker
- Additional 3rd Servo Driven 410MM Wicket Arm (For R.H. Machine)
- Seal Bar for LD Side Sealing [ 0-50 micron ] for R.H.
- Seal Bar for LD Side Sealing [ > 40 micron ] for R.H.
- Seal Bar for PP Side Sealing for R.H.
- Servo Driven Attachment (Max .325 CPM) for Square Bottom / Round Bottom / Cross seal / Pre-seal etc.
- Sealing Bar [With Tool ] For Square Bottom Bag (Standard)
- Sealing Bar [With Tool] For Pre Sealing
- Wicket Hole Punch Module With Edge Guide
- Wicket Hole Punch Tool – 16 mm (5/8″) dia hole (Piranha): 2
- Tear Slit Punch Unit on Wicket Hole Punch Trolley
- SERVO MULTI HOLE PUNCH ASSEMBLY WITH TROLLEY, 6 DIA Punch (8 x 4 Row = 32 Nos), Servo Operating Assembly
- 10 – Incremental for Bottom gusset upto 125 mm depth
- …
