Ref. 15129- USED MÜHLBAUER LP 5570 TWIN, YEAR 2015
- Manufacturer: MÜHLBAUER
- Model: LP 5570
TWIN
- Year: 2015
- The Mühlbauer LP 5570 laminating system is perfectly suited for complex card designs, such as high-security cards. It is designed for laminating pre-laminated cards, plastic cards, smart cards, and contactless cards.
- The system meets the latest requirements for cost-effectiveness, sustainability, and both product and process quality. All important process parameters, such as temperature, pressure, and cycle time, are continuously monitored and individually regulated.
- These features allow for optimal lamination of all common card materials, including ABS, PVC, PC, PET, PETG, PS, PE, and PP.
- Optional features include weight compensation and a vacuum chamber for the hot press, enabling the lamination of more complex cards. The LP 5570 can be configured with four, six, or eight openings, and each system can accommodate between six and twelve layers per opening, depending on the production material.
- KEY FEATURES
- Full-size automatic sheet laminating system
- Suitable for complex card constructions, such as ID cards and other high-security cards
- Available in single or double stacking configurations
- Fully modular system design
- Wide range of programmable process parameters
- Intuitive user interface for easy and efficient system and process operation
- Optimized energy management system for environmentally friendly and cost-saving operation
- Uniquely designed heating plates for perfectly homogeneous temperature conditions
- MB INCAPE ready
- PRODUCT
- Up to 144 (SINGLE STACK) / 288 (DOUBLE STACK) sheets per hour; depending on the material and arrangement
- …
