Ref. 15033- USED VEA ENTRY 1300X, YEAR 2002
- Manufacturer: VEA
- Model: ENTRY 1300X
- Year: 2002
- Solventless
- With 16 green conveyor rollers
- 1×44 cm + 2x50cm + 1×54 cm + 1×54,5 cm + 1×59 cm
- 1×61 cm +1×69 cm + 1×72 cm + 1×75 cm + 1×86 cm
- 1×89 cm + 1×95 cm + 1×99 cm + 1×110 cm + 1×123 cm
- 3 red spreader roller/presser
- 1 conveyor roller carrier up to 18-places
- 1 matrix mixer – for solventless two-component adhesives with filling of the resin component – cm.154 x 120 x 80 – 5 kw – prod 90 kg/h
- Film nominal with 1300 mm
- Max film width 1315 mm
- Max spreading
- Minimum film width 50 cm
-
Maximum throw film unwinding kg.25
-
Maximum shooting film in wrapping – descending pull kg.35
- Minimum film unwinding kg.3,5
- Maximum film thickness in wrapping 300 microns
- Maximum diameter winding / unwinding rolls cm.86
- Maximum weight of reels winding / unwinding kg according to the material
- Unwinding core diameter from 3 to 6 inches
-
Inch wrapping core diameter 6
- Maximum film speed m / min 300
- Water supply for heating units
- Fluid to use: water
- Minimum pressure 1 bar
- Maximum pressure 3 bar
- Water hardness from 9 to 12 French degrees
- Consumption (liters / hour only in case of intervention of the cooling circuit) 600
- Supply line («G) 3/8
-
Pneumatic supply: dehumidified, non-lubricated air
- Pneumatic pressure from 7 to 10 bar
- Air consumption liters / min 60
- Supply conduit diameter («G) 3/8
- Power supply for cooling calender: water
- Maximum pressure 3 bar
- Water Hardness from 9 to 12 French degrees
- Flow rate liters
- Supply line («G) 3/4
- …
