Ref. 13003- MARK ANDY DG1-13, YEAR 2009

Ref. 13003- USED MARK ANDY DG1-13, YEAR 2009

Manufacturer: MARK ANDY
Model: DG1-13
Year: 2009
Width: 330 mm
UV flexo
Speed: 15 m/min
Mark Andy Digital One hybrid press using CMYK toner plus basic converting
Servo driven unwind with 3 inch core capacity – 30 inch maximum diameter
Web guide for tension registry management
Web cleaner to protect the digital engine from debris and ensure high quality print
2 Servo driven pacing and tension control station
2 Advanced dancer systems with responsive feedback
Digital print engine with operating interface on pivot arm
Servo driven print station with slide out tray for easy cleanup
Air cooled UV LED curing system
2 Elevated auxiliary decoration capstan rolls (for cold foiling and laminating)
Adjustable RD Score equipped with two scoring units
Servo driven die cut station with electronic registration – 10 inch to 18 inch maximum repeat
2 Servo driven rewinds
Cartridge slitter system with three blades
Onboard ultra-quiet pneumatic compressor
3 Localized electrical & servo power system cabinets for easy access and small footprint
Central master pneumatic distribution panel
96T Print cylinder
96T Magnetic cylinder
Praxair anilox roll
…
