Ref. 1072- USED SOMTAS BAG MASTER TC 18-46 FLAT HANDLE SQUARE BOTTOM, YEAR 2023
- Manufacturer: SOMTAS
- Model: BAG MASTER TC 18-46 FLAT HANDLE SQUARE BOTTOM
- Year: 2023
- TC 18-46 FLAT HANDLE MODEL II SQUARE BOTTOM PAPER BAG MAKING MACHINE
- Maximum Speed: 120 m/min*
- Maximum Capacity: 150 bag/min
- Optimum Capacity: 90-120 piece/min
- Cutting length: 360-770 mm
- Bag width: 180-460 mm(2Ply without the Patch), 200-460 mm(With Patch)
- Bottom width: 80-230 mm
- Dimensions (WxLH): 6199 mm X 15726 mm X 2951mm
- MATERIAL SPECIFICATIONS:
- Paper thickness: 70-120 gsm
- Paper width max: 1410 mm
- Paper reel diameter max: 1250 mm
- Paper weight max: 1000 kg
- Paper reel core diameter: 76 mm
- FLAT HANDLE & HANDLE PATCH
- Patch Width: 175 mm
- Patch Cutting Length: 70 mm (Standard)
- Patch Paper Weight: 70-80 gsm
- Patch Paper Roll Diameter: 1000 mm
- Patch Paper Roll Stand: 2 stands
- Patch Paper Roll Diameter: 76 mm
- Handle Paper Width: 80 mm in flat, folded 6 times into 18 mm Width
- Handle Paper Cutting Length: 350 mm
- Handle Paper Weight 70-80 gsm
- Handle Paper Roll Diameter: 1000 mm
- Handle Paper Roll Stand: 2 stands
- …
